Case Of 2 – 2×2 LED Flat Panel Light – Wattage Adjustable 20W/30W/40W – Color Tunable 30K/40K/50K – Euri Lighting

This powerful 2ft. x 2ft. Wattage Adjustable & Color Tunable LED Backlit Flat Panel by Euri Lighting is what you have been searching for. This LED flat panel light would work great for offices or other commercial and industrial applications. It is wattage and color adjustable to fit the needs of the environment being installed into. These features are only just the tip of the iceberg as this panel also boasts being dimmable, damp rated, and comes in a two pack to double your energy savings.

Specifications:

• Case Size: 2 LED Panels
• Panel Size: 2ft. x 2ft.
• Wattage Adjustable: 20W, 30W, or 40W
• Lumen Output by Wattage:
  • 20W: 2600 Lumens
  • 30W: 3900 Lumens
  • 40W: 5200 Lumens
• Efficacy: 130 Lumens/Watt
• Color Tunable:
  • 3000K: Soft White
  • 4000K: Bright White
  • 5000K: Cool White
• Dimmable: Yes
• Input Voltage: AC100-277V
• Beam Angle: 110°
• CRI: 80
• LED Lifespan: 50,000 Hours
• Operating Temperature: -13°F to 113°F
• Other Notable Features:
  • DLC Listed V5.1
  • ETL Listed
  • Damp Rated
  • Flicker Free Driver

Product Dimensions – 23.7″ L x 23.7″ W x 1.57″ H

What is the difference between Edge-Lit vs Back-Lit LED Light Panels? Which type of LED panel is the best?

LED panels are either edge-lit or back-lit led fixtures. Edge-lit panels have LEDs arranged along the inside edges of the fixture. A light guide panel directs the light to a plastic diffuser that evenly distributes the light across the surface of the lens. The edge-lit panels have a thinner profile and versatile mounting options. Edge-lit panels can be installed in standard grid ceilings (like troffers), suspension mounting, or flush mount to the ceiling or wall. Some edge-lit panels require a separate surface or suspension mounting kits to be able to install in those situations.

In contrast, back-lit led panels have their LEDs arranged directly behind the lens across the back cavity of the panel fixture. Back-lit panels don’t require extra light guide plate that the edge-lit panels require – instead back-lit LED panels have a diffuser that ensures smooth light distribution without hotspots or glare. Back-lit led panels are about twice as deep as edge-lit flat panels to accommodate the LED placement on the back of the fixture. Due to the extra thickness, most back-lit panels can only be used in drop or grid ceiling installations. The back-lit LED panels require minimal components compared to edge-lit panels and regular troffers making back-lit LED panels lightweight and easier to handle.

The application will determine which LED panel should be used as both types have different features that should be taken into consideration before installation.

How do you install a LED flat panel light fixture?

Most LED flat panel light fixtures can be installed three ways: via drop-in ceilings, surface or suspension mounted, or ceiling mounted. Ceiling mounted LED flat panels require a mounting kit that is sold separately from the light fixture. The instructions should always be consulted to make sure the fixture is installed correctly using the necessary tools and/or accessories.

This LED flat panel is also DLC Premium V5.1 listed meaning it is highly energy efficient and may qualify for utility rebates in certain areas. Check out our Rebate Assistant tool to find if this product qualifies for you!
